Gas flushing with precise ratio control
Modified Atmosphere Packaging (MAP) Machines for Food Shelf Life Extension
Extend Food Shelf Life with MAP Technology
Map packaging machines by ALF PACK are engineered to replace the air inside a package with a gas mixture — commonly nitrogen and CO₂ — to inhibit microbial growth and oxidation. This technology is widely used in meat, seafood, baked goods, and prepared meals. Our MAP machines deliver freshness, safety, and extended shelf life.
Technical Specifications of our map sealer
Widely used in：
|
Model
|
|
|
Maximum width of roll film(mm)
|
370
|
|
Maximum diameter of roll film(mm)
|
220
|
|
Gas replacement rate
|
≥99%
|
|
Gas distribution accuracy (%)
|
Volatility±2%
|
|
Packaging speed(times/min)
|
5～6
|
|
Production capacity (box/hour) output 1
|
≈360
|
|
Production capacity (box/hour) output 2
|
≈640
|
|
Production capacity (box/hour) output 4
|
≈1200
|
|
Vacuum pump displacement（m³/h）
|
/
|
|
Source(V/Hz)
|
220/50
|
|
Total power(kw)
|
2.1
|
|
Working air pressure(Mpa)
|
0.6～0.8
|
|
Equipment weight(kg)
|
100
|
|
Equipment size(mm)
|
1020×950×660
|
|
Conversion of packaging gross weight and volume(kg)
|
135
|
|
Packaging box size(mm)
|
1080×1020×740
|
|
Maximum size of tray (mm) out of 1
|
/
|
|
Maximum size of tray (mm) out of 2
|
310×200×60（×2）
|
|
Maximum size of tray (mm) out of 4
|
200×140×60（×4）
|
|
Actual gross weight
|
114
|
|
Outer gross size
|
1100*1100*860
|
|
model
|
|
|
packaging type
|
Film, Foil
|
|
packaging material
|
Plastic, paper
|
|
Voltage
|
380V, 220V
|
|
automatic grade
|
Automatic
|
|
warranty
|
1 Year
|
|
Sealing Type
|
Heat Sealing
|
|
Weight (KG)
|
220
|
|
driven type
|
Pneumatic
|
|
Application
|
Food, Beverage, Commodity, Chemical
|
|
place of origin
|
Nanjing,China
|
|
brand name
|
Fuou
|
|
dimension(l*w*h)
|
124*110*170
|
|
key selling points
|
Easy to Operate, Remote Monitoring, Low Noise Level, High-accuracy, Flexible Manufacturing, High Safety Level
|
|
machinery test report
|
Provided
|
|
video outgoing-inspection
|
Provided
|
|
core components
|
PLC, Gear, Gearbox, Engine, Pressure vessel, motor, Bearing
|
|
After-sales Service Provided
|
Video technical support, Online support
|
|
Suitable for
|
Food Packing
|
|
Function
|
High Effieciency
|
|
Usage
|
Aliuminium Foil Lid Sealing
|
|
Material
|
304 Stainless Steel
|
|
Application fields
|
Food Product
|
|
Feature
|
High Efficiency Easy Operation
|
|
Sealing material
|
PP.PE.PET.PS.Aluminum Foil
|
|
Applicable Industries
|
Beverage
|
|
Machine Type
|
Automatic Sealing Equipment
|
Sealer Map's Key Features
Fresh Meat & Poultry
Extend shelf life and preserve color, texture, and flavor in beef, chicken, and lamb.
